伊朗采购需求:5英寸,COB UART液晶模块
原文:5 inch,cob uart lcd module
参考产品图片:


-
Facebook
-
伊朗
- 2025-09-14
-
alizad****@****l.com
采购商询盘内容
I'm currently working with a 5-inch HMI LCD module and need detailed information regarding the pinout for its 10Pin 1.0mm FCC connector. Specifically, I'm looking for the assignments related to VCC, GND, TX, RX, and any other relevant signals.
If you could provide the exact pin configuration or direct me to a reference document that outlines these details, it would be really helpful. Your assistance in this matter would be greatly appreciated as it will aid in my ongoing project! Thank you!
我目前正在使用一个 5 英寸 HMI LCD 模块,需要有关其 10Pin 1.0mm FCC 连接器引脚排列的详细信息。具体来说,我正在寻找与 VCC、GND、TX、RX 以及其他相关信号相关的分配。
如果您能提供具体的引脚配置,或者给我提供一份包含这些细节的参考文档,那将非常有帮助。非常感谢您的帮助,因为这将对我正在进行的项目有所帮助!谢谢!
